1. Slickflow. Designer is a browser-based web graphics designer that supports HTML5 and SVG technology：

1) HTML5，BPMN graphic frame, powerful drawing function；
2) Pure HTML, JQuery/Ajax development and implementation, completely separated from the back-end, suitable for .NET, Java, PHP and other project environments；
3) Support mainstream browsers, such as IE, Firefox, Chrome, etc.

2. Support XML format export of process data.
3. Support process graphics PNG format storage and export.

1. WebDemo demonstrated the approval business process of the common employee leave process in the enterprise. The general introduction is as follows:

1) Employees fill out the leave form and go to different branches according to the number of days of leave;
2) Approval by the department manager within 3 days, and approval by the general manager for more than 3 days;
3) Then the personnel manager will finally archive;
4) Fill in the handling opinions during the approval process;

2. The interface has a leave form to fill in, and the next step is to transfer role personnel selection.
3. Display information such as to-do, done, and process definition icons.
4. Realize the functions of process start, run, jump, conditional branch, task distribution and so on.

1. MvcDemo example is an actual business process that implements a foreign trade commodity order process. The general introduction is as follows:

1) Synchronization: The online order data is synchronized to the internal order system, and the execution role is a salesperson;
2) Dispatch: that is, the salesman will place the orders and divide the orders; the executive role is the salesman;
3) The executive role of proofing is the proofer;
4) The executive role of production is the merchandiser;
5) The executive role of quality inspection is quality inspector;
6) The executive roles of weighing and shipping are all packers.

2. The buttons on the interface have access control, and the corresponding operations can be performed according to the user login under different roles.
3. Realize the functions of process start, run, jump, conditional branch, task distribution and so on.

The web form designer based on HTML5 and Bootstrap framework is roughly introduced as follows:

1) Realize the interface display and attribute definition of common controls on the form;
2) Realize form element definition SCHEMA database storage;
3) Support multi-column data format definition;
4) Support EAV model, used for dynamic and expandable field filling data storage;
5) Realize the interface rendering and display of the HTML content of the form;

It adopts Bootstrap framework and supports excellent open source components such as Ag-Grid and zTree.

1) zTree tree control components;
2) Ag-Grid data processing components, rich plug-in support;
3) JQuery/Json/Mvc/WebApi separate data processing from front and back ends;
4) Dapper framework multi-database support, SQLServer, My SQL, Oracle, King Base, etc.;
5) Multi-Tab page, multi-column main page layout;

A well-defined authority model supports authority calculation, and realizes the background authorization operation and front-end verification function of the authority management system.

1) Based on the Slick One open source Web rapid development framework, focusing on reuse;
2) User login verification, FORM authentication, cookie storage, Web Api access verification;
3) Role authorization and user authorization are supported at the same time, and the expression of the authority relationship is simple and clear;
4) Dapper framework multi-database support, SQLServer, My SQL, Oracle, King Base, etc.;
5)Enterprise version user support, provide detailed technical information and training.
